Custom Lithium Thionyl Chloride Battery Manufacturers Price List

Company Advantages

· The production method of WECODO lithium thionyl chloride battery manufacturers is improved combining the newest technology.

· In terms of the quality, it is greatly improved through breakthrough progress.

· Shenzhen WECODO Technology Co., Ltd. has gained rapid development in both product and market thanks to more than decade years of product R&D and production experience.

Items	Specification	Remarks
Model	ER10450
Rated voltage	3.6V	At 3mA +20˚C
Rated capacity	1000mAh	3mA +20˚C,2.0V
Open-circuit voltage	3.66V	At +20˚C
Max constant discharge current	10mA	At +20˚C
Max pulse discharge current	20mA	At +20˚C
Storage temperature range	+30˚C(+86˚F)	Max
Operating temperature range	-55˚C~+85˚C	-76˚F~+185˚F
Air tight test	No electrolyte leakage	Normal use
Size	10.5*45.0mm
Weight	9.0g
Self discharge	≤1% per year
Terminal	radial tabs, radial pins, axial leads, flying leads
We also supply ER10240, ER10280, ER10450, ER14250, ER14335, ER14505, ER17335, ER17505, ERI8505, R26500,ER34615, ER341245, ER9V



product description

Key features

● High and stable load voltage ● Superior drain capacity ● Low self-discharge rate(less than 1% after 1 year of storage at 20°C) ● Stainless steel container ● Hermetic glass-to-metal sealing ● Laser welding ● Non-flammable electrolyte

Main applications

● Radio communication and other military applications ● TPMS ● RFID ● Alarms and security systems ● Beacons and emergency location transmitters ● GPS equipment ● Metering systems ● Led lighting applications >Others

Storage

● Cells should be stored in a clean &dry(less than 30% RH) area ● Temp. should not exceed +30°C

Warning

● Do not use if cell casing is mangled >Do not use different model of cell in series ● Soldering the tag should be finished in few seconds ● Do not try to recharge

product data

1 (3)

2 (3)

3 (4)

4 (3)

Company Features

· WECODO has enough strength to produce high quality lithium thionyl chloride battery manufacturers with competitive price.

· With an authorized export right, we are allowed to participate in and conduct various kinds of overseas businesses. The export right also indicates that all of the products or services including lithium thionyl chloride battery manufacturers we provide are legal and meet relevant regulations. The factory has introduced many international cutting-edge manufacturing or assisting facilities. These facilities are able to detect most kinds of product defections, which gives us the capability to manufacture high-quality and standardized products. We have been licensed with an export right. This right allows us to conduct business in foreign lithium thionyl chloride battery manufacturers markets, including R&D, production, and marketing, and we are qualified and authorized to participate in international exhibitions.

· Through WECODO, we provide customers with the most reliable products and excellent services. Contact us!

Product Details

lithium thionyl chloride battery manufacturers produced by WECODO are of excellent quality and the specific details are as follows.
