Custom Lithium Polymer Battery 4.2V by WECODO
Product details of the custom lithium polymer battery
Product Overview
Shenzhen WECODO Technology Co., Ltd. continuously works to rejuvenate and expand its capabilities by developing new custom lithium polymer battery products. The product has a long service life and a long-lasting performance. custom lithium polymer battery of WECODO can be widely used in various fields. Shenzhen WECODO Technology Co., Ltd. fully implements ISO9001:2000 quality management system.
Product Information
Compared with custom lithium polymer battery of peers, WECODO's custom lithium polymer battery has the following advantages.
| Items | Specification | Remarks |
| Model | PL505060 | |
| Rated voltage | 3.7V | |
| Rated capacity | 2000mAh | 0.2C discharge |
| Initial cell impedance | ≤ 30 mΩ | 3.7V AC 1KHz measured |
| Initial Voltage | 3.75V-3.95V | At +20˚C |
| Limited Charge Voltage | 4.2V | CC to CV |
| Cut-off Voltage | 2.75V | Load Voltage when discharge ended |
| Standard charge current | 400mA | |
| Standard charge time | 6-7 hours | |
| Rapid charge current | 2000mA | |
| Rapid charge time | 2-3 hours | |
| Standard discharge current | 400mA | CC discharge to 2.75 V |
| Max pulse discharge current | 2000mA | CC discharge to 2.75 V |
| Storage temperature range | 15˚C~+35˚C | recommend |
| Operating temperature range |
charging: 0˚C~+45˚C |
discharging: -10˚C~+60˚C |
| Size |
Thickness: 5mm |
Width: 50mm Length: 62mm |
| Weight | 40.0g |
Company Information
Shenzhen WECODO Technology Co., Ltd. is devoted to developing and manufacturing high quality custom lithium polymer battery. In contrast to other similar types, our custom lithium polymer battery is well-produced by our advanced technology. Shenzhen WECODO Technology Co., Ltd. will continue to provide a high quality custom lithium polymer battery and professional services. Contact!
We supply our products of good quality and affordable price in long term. Please feel free to consult us!
Shenzhen WECODO Technology Co., Ltd., focus on R&D and provide best services in high energy and IT technology, having advanced producing bases and our own battery brand WECODO.
