Lithium Polymer Battery for Drone 600mAh by WECODO

Items	Parameters	Remarks
Model	PL503040
Rated Capacity	600 mAh	0.2C discharge
Cell Weight	12g
Cell Initial Impedance	≤ 80 mΩ	3.7V AC 1KHz measured
Normal Voltage	3.7 V
Initial Voltage	3.75V~3.95V
Limited Charge Voltage	4.2 V	Voltage of cc charge to cV charge
Standard Charging Method	0.2C CC current charge to 4.2V, then CV charge till current declines to 0.01C
Cut-off Voltage	2.75 V	Load Voltage when discharge ended
Standard Charging Current	120 mAh (0.2C)
Standard Charging Time	6~7 hours	CC charge to 4.2 V, then CV charge till current declines to less than 0.01C
Rapid charging Current	600 mAh (1.0c)
Rapid Charging Time	2~3 hours
Standard Discharging Current	120 mA (0.2C)	CC discharge to 2.75 V
Max. Discharging Current	600 mA (1.0C)	CC discharge to 2.75 V
Operating Temperature	Charging :0~45°C, Discharging :-10~60°C

Application Scenario

Security Systems

Reliable Power Source

Medical Equipment

Long-lasting Operation

Smoke Detectors

High-Energy Consumption

Portable Electronics

AA Compatibility

Company Advantages

· These WECODO lithium polymer battery for drone are designed and developed in line with industry norms and standards.

· Thanks to the advanced technology, our lithium polymer battery for drone can be controlled intelligently.

· In fact, the product performs well than others in the industry.

Company Features

· Shenzhen WECODO Technology Co., Ltd. is the professional supplier of the international high-quality lithium polymer battery for drone provider.

· The lithium polymer battery for drone production procedure utilizes smart production technology for precise control.

· From design concept to the finished product, we provide a dedicated, personal service. Contact!

Application of the Product

The lithium polymer battery for drone produced by WECODO is widely used.

WECODO always pays attention to customers. According customers' actual needs, we could customize comprehensive and professional solutions for them.
