Super Polymer Lithium Ion Battery 500mAh by WECODO

Product details of the super polymer lithium ion battery

Product Overview

In order to strictly control quality, Shenzhen WECODO Technology Co., Ltd. selects super polymer lithium ion battery as raw material. To ensure durability, our highly skilled QC professionals strictly inspect the products. The super polymer lithium ion battery produced by our company can be applied to different fields and scenarios. So the different requirements of different people can be satisfied. The assurance of super polymer lithium ion battery quality has helped WECODO attracted more and more customers.

Product Information

WECODO pays great attention to details. And the details of super polymer lithium ion battery are as follows.

Items	Parameters	Remarks
Model	PL503035
Rated Capacity	500 mnAh	0.2C discharge
Cell Weight	about 15g
Cell Initial Impedance	≤ 80 mΩ	3.7V AC 1KHz measured
Normal Voltage	3.7 V
Initial Voltage	3.75V~3.95V
Limited Charge Voltage	4.2 V	Voltage of cc charge to cV charge
Standard Charging Method	0.2C CC current charge to 4.2V, then CV charge till current declines to 0.01C
Cut-off Voltage	2.75 V	Load Voltage when discharge ended
Standard Charging Current	500 mA (0.2C)
Standard Charging Time	6~7 hours	CC charge to 4.2 V, then CV charge till current declines to less than 0.01C
Rapid charging Current	500 mA (1.0C)
Rapid Charging Time	2-3 hours
Standard Discharging Current	100 mA (0.2C)	CC discharge to 2.75 V
Max. Discharging Current	500 mA (1.0C)	CC discharge to 2.75 V
Cell Dimension	T*W*H: 5.0*30.5*35.5 mm
Operating Temperature	Charging :0~45°C, Discharging :-10~60°C

Company Information

Shenzhen WECODO Technology Co., Ltd. is a company in shen zhen. Rechargeable Lithium Battery,Primary Lithium Battery,Battery Related is one of our main products. 企业名称] always adheres to the business philosophy of 'quality wins the market, reputation creates the future' and carries forward the enterprise spirit of 'determined and progressing, developing and innovating'. With the consistent focus on integrated industrialization, we strive to improve our core competitiveness and to become a modern enterprise with a wide brand recognition, great innovation ability, and good economic benefits. WECODO has formed an excellent team with a large number of senior professionals. Meanwhile, we have established good cooperation with many outstanding enterprises in the industry. All this provides a strong guarantee for high-quality products. With professional engineers and technicians in our company, WECODO is able to provide one-stop and comprehensive solutions for customers.
Over the years, we have been dedicated to the R&D and production of our products. If you want to know more about our products, please contact our online customer service staff.
